Chip: |
Ankai AK3918EN080V300 |
APP: |
YOOSEE |
Main processor: |
single core 1.2GHZ |
Operating system: |
Embedded LINUX operating system |
Image sensor: |
2 million pixel CMOS |
Image coding standard: |
H.265 |
Video standard: |
PAL |
Monitoring image quality: |
1920*1080 |
Video quality: |
VGA@25fps |
Image motion detection: |
support |
Capturing function: |
support |
Minimum illumination: |
0.1LUX/F1.2 |
Coding standard: |
G.711A |
Audio input: |
Built-in 40db microphone |
Audio output: |
Built-in 8 ohm/1 watt speaker |
Recording method: |
manual recording, dynamic detection recording, timing recording |
Video storage: |
TF card, cloud storage |
Alarm input: |
motion detection alarm, email alarm, mobile phone APP alarm |
Intelligent: |
Custom voice alarm, invading warning |
Battery |
Inset 18650 battery |
Network: |
WIFI connection |
TF: |
One TF interface |
WiFi: |
Support 5g & 2.4g |
PTZ control: |
built-in horizontal and vertical motors |
Power supply: |
DC 5V 2A |
Power consumption: |
Maximum 1W |
Working temperature: |
-20℃±60℃ |
Working humidity: |
10%-90% |
Standard box: |
20 sets/box |
Outer box packing size: |
40.5*25.5*57cm |
Gross weight: |
16.05kg |
Color box packing size: |
195*120*110mm |
Net weight |
0.45kg |
Gross weight |
0.754kg |
Color: |
Color: white |
