Si-TPV 3100-55A Exceptional Aesthetics thermoplastic silicone-based elastomers
Description
Si-TPV is a dynamic vulcanizated thermoplastic Silicone-based elastomers which made by a special compatible technology , it helps silicone rubber dispersed in TPU evenly as a 2~3 micron droplets under microscope . This unique material provides a good combination of properties and benefits from thermoplastics and fully cross-linked silicone rubber. Suits for wearable device surface, Phone bumper ,Electronic devices accessories ( earbuds ,eg ), overmolding , artificial leather, Automotive, high-end TPE, TPU industries ….
Remark
The blue part is the flow phase TPU, which provides excellent mechanical properties.
The green part is silicone rubber particles provides silky skin-friendly touch, high and low-temperature resistance, weather resistance, stain resistance, etc.
The black part is a special compatible material, which improves the compatibility of TPU and silicone rubber, combines the excellent properties of the two, and overcomes the shortcomings of a single material.
3100 series
| Test item | 3100-55A | 3100-65A | 3100-75A | 3100-85A |
| Modulus of Elasticity ( Mpa ) | 1.79 | 2.91 | 5.64 | 7.31 |
| Elongation at break (%) | 571 | 757 | 395 | 398 |
| Tensile strength(Mpa) | 4.56 | 10.20 | 9.4 | 11.0 |
| Hardness ( Shore A ) | 53 | 63 | 78 | 83 |
| Density (g/cm3) | 1.19 | 1.17 | 1.18 | 1.18 |
| MI( 190℃,10KG) | 58 | 47 | 18 | 27 |
3300 series — Antibacterial
| Test item | 3300-65A | 3300-75A | 3300-85A |
| Modulus of Elasticity ( Mpa ) | 3.84 | 6.17 | 7.34 |
| Elongation at break (%) | 515 | 334 | 386 |
| Tensile strength(Mpa) | 9.19 | 8.20 | 10.82 |
| Hardness ( Shore A ) | 65 | 77 | 81 |
| Density (g/cm3) | 120 | 1.22 | 1.22 |
| MI( 190℃,10KG) | 37 | 19 | 29 |
Mark: The above data is only used as a typical product index, not as a technical index
Benefits
1. Provide the surface with Unique silky and skin-friendly touch, soft hand feel with good mechanical properties .
2. Not contain plasticizer and softening oil, no bleeding / sticky risk, no odors.
3. UV stable and chemical resistance with excellent bonding to TPU and similar polar substrates.
4. Reduce dust adsorption , oil resistance and less pollute .
5. Easy to demould, and easy to handle
6. Durable abrasion resistance & crush resistance
7. Excellent flexibility and kink resistance
How to use
1. Directly injection molding
2. Mix Si-TPV® 3100-65A and TPU at a certain proportion , then extrusion or injection
3. It can be processed with reference to TPU processing conditions , recommend processing temperature is 160~180 ℃
Remark
1. The process conditions may vary with individual equipment and processes .
2. A desiccant dehumidifying drying is recommended for all drying
Typical application case study
The advantages of wristband which made by Si-TPV 3100-65A:
1. Silky, Friendly-skin touch, suits for kids as well
2. Excellent encapsultaion performance
3. Good dyeing performance
4. Good release performance and easy for processing
Package
25KG / bag , craft paper bag with a PE inner bag
Shelf life and storge
Transport as non-hazardous chemical. Store in a cool, well ventilated place.
Original characteristics remain intact for 12 months from the production date, if kept in recommend storage.
