FSK-20 3

Introduction

Current: 0.1A, 3A,Voltage:AC 125V/250V, DC 12V/24VApproved: UL,cUL(CSA),VDE,ENEC,CQC

Product Details

Product Tags

Switch action Characteristics

The defining characteristics of operation Operating Parameter Value Units
 src=
Free Position FP 15.9±0.2 mm
Operating Position OP 14.9±0.5 mm
Releasing Position RP 15.2±0.5 mm
Total travel Position 13.1 mm
Operating Force OF 0.25~4 N
Releasing Force RF N
Total travel Force TTF N
Pre Travel PT 0.5~1.6 mm
Over Travel OT 1.0Min mm
Movement Differential MD 0.4Max mm
