2019 Chinese Factory Surface Mount Ex-proof Lamp for Hazardous Location

Introduction

LED explosion-proof lights can provide conventional lighting in dangerous places, such as oil refineries, gasoline filling stations, distillers, pumping stations, mines, ships, paint factories and other places with high humidity, high temperature and dust.Our LED explosion-proof floodlights are easy to install and have an industry-leading 100,000-hour rated bulb life and a 3-year warranty (optionally 5 years). Please refer to the order style below to learn about our products that meet the requirements. Please contact us for prices or more information.

Product Details

Product Tags

Parameter

Model TY/TLED201 TY/TLED202
Rated Power 200W/300W/400W 120W/160W/200W
Working Voltage AC110V-280V DC12-42V  50-60HZ
Power Factor 0.95
IP Grade IP67
Anti-corrosion Grade WF2
Color Temperature 5500K-6500K
Irradiation Angle 120°/140°
Introducing Device G3/4 inlet specification, suitable for φ8mm-φ11mm
Installation Height Different power can be installed at a height of 4.5 meters -40 meters
Ex Marking Exd IIBT4 Gb
Executive Standard GB3836.1/GB3836.2/IEC60079-0/IEC60079-1/EN60079-0/EN60079-1

Light Source

Rated Power(W)

Luminous Flux(Lm)

Life Span(h)

LED

40

5500

100000

LED

50

6600

100000

LED

60

7700

100000

LED

80

11000

100000

LED

100

13200

100000

LED

120

13200

100000

LED

150

16500

100000

LED

200

22000

100000

LED

300

33000

100000

LED

400

44000

100000

Features

  • What kind of system driver does the lighting lamp of dangerous places with better design power drive, which can drive high-quality lighting lamps?
  • Class I and Class II are approved
  • Smaller size, the new design uses the latest LED technology. Smaller size, longer service life and higher efficiency.
  • Easy to install-the power port on the side allows you to wire as needed. The pre-installed wires and hooks make installation easy. Simply replace an existing lamp or perform a new installation. The product weighs only 8.52 pounds and is easy to handle.
  • Bright, direct and durable-120 degree light produces a broad uniform light. 100,000 LEDs save the trouble of replacing bulbs-the aluminum housing with a high-tech heat sink protects the LED driver. Better heat dissipation ensures longer LED life and safety. To rated and warranty listed safety and 1 year rock-solid warranty.

Application

11.2
oil factory
chemical factory
oil station

Summary

These lights are the latest LED technology. Compared with traditional high bay lights, they are smaller and more efficient, they look better, they last longer and are easier to install.

Replace the old Class 1 and Class 2 with high-efficiency LEDs. Save money and reduce the frequency of bulb replacement with 100,000 hours of rated LEDs. Fixtures are also ideal for new installations. Save money and improve lighting.
